Acoustic Imager

Fluke ii910

Acoustic Imager

The fastest, easiest, and safest way to detect and locate Partial Discharge.

With an expanded frequency detection of range up to 100 kHz the Fluke ii910 Precision Acoustic Imager enables you to visually see partial discharge problems, even in their earliest stages. Spot problems before they occur to minimise downtime, save on energy costs, and prevent catastrophic failures.

  • Safely detect PD from up to 120 m in distance

  • Use the built-in PDQ mode to capture, track, and analyse the severity and type of partial discharge

  • Capture images and videos with one button for easy reporting. Combine with PDQ data to generate comprehensive reports

Download Datasheet
Download Datasheet
Sensor
Frequency Band
2 kHz to 100 kHz
Nominal Frame Rate
25 fps
Built-in Digital Camera (visible light)
Field of View
63° ± 5°
Focus
Fixed lens
Display
Size
7” LCD with backlight, under-sunlight readable
Resolution
1280 × 800 (1,024,000 pixels)
Touchscreen
Capacitive
Acoustic Image
Yes, SoundMap™ image
Acoustic Measurements
12.1 dB SPL to 114.6 dB SPL ±1 dB SPL 2 kHz
4.4 dB SPL to 101.2 dB SPL ±2 dB SPL 19 kHz
12.8 dB SPL to 119.2 dB SPL ±1 dB SPL 35 kHz
19.8 dB SPL to 116.1 dB SPL ±3 dB SPL 52 kHz
41.4 dB SPL to 129.0 dB SPL ±1 dB SPL 80 kHz
54.4 dB SPL to 135.5 dB SPL ±1 dB SPL 100 kHz
Auto Max/Min dB Gain
Auto or manual, user selectable
Frequency Band Selection
User selectable through user-made pre-sets or manual entry
